Application
The evaporative condenser can be used in the soft water cooling and sealing cycle of the iron-making blast furnace; the cooling water of the steel-making heating furnace, crystallizer, and oxygen lance; the cooling water system of steel rolling and coking; Cooling water of blower, motor and other equipment
Features
Compared with traditional air cooled, open cooling system, the evaporative condensers have the advantaged of water-saving, electricity-saving,small area and easy maintain.
2.Coil type counter flow evaporative condenser
Advantages
(1).Without fill, long service life.
(2). Cheaper than box type evaporative
(3). Fully welded and sealed, not easy to leak
Disadvantage
(1).Hard to find leak point and maintain when leaking due to fully welded.
(2).The serpentine tube structure has large wind resistance.
(3).Many takeovers and complicated pipelines
3.Coil type cross flow evaporative condense
Advantages
1.Using PVC fill to replace part of heat exchange coil, heat transfer efficiency is higher than counter type
- Light weight, small initial investment
Disadvantage
- Fill is prone to blockage and need to be cleaned each 2 years, replaced 3~5 years.
- Large installation area
